Heavy duty lathe CW61125C
Inquire NowDescription
The Heavy Duty Lathe CW61125C is a robust and high-performance machine designed for precision machining of various materials. With a maximum swing over the bed ranging from Ф1000mm to Ф1400mm, and a spindle bore of Ф130mm, this lathe accommodates a wide range of workpieces. The spindle speed adjusts between 2.5 to 250 RPM, powered by a reliable 22kW main motor, ensuring efficient operation for both heavy and intricate tasks.
This lathe is ideal for professional workshops looking to enhance their machining capabilities. Its formidable structure allows for heavy workloads with a maximum weight capacity of 5000 kg, making it suitable for large components. The CW61125C offers precision and functionality, featuring multiple swing diameters and lengths, making it versatile for various applications.
Specifications
| Item | Specifications |
|---|---|
| Max Swing Diameter Over Bed | Ф1000mm/1250mm/1400mm |
| Max Swing Diameter Over Carriage | Ф600mm/865mm/1015mm |
| Max Swing Diameter Over Gap | Ф1380mm/1750mm/1900mm |
| Width of Bed | 755mm |
| Effective Length of Gap | 590mm |
| Max Turned Length | 1.5/2/3/4/5/6/7/8/10/12m |
| Max Length of Workpiece | 1.35/1.85/2.85/3.85/4.85/5.85/7.85/9.85/11.85m |
| Max Weight of Workpiece | 5000kg |
| Spindle Bore | Ф130mm |
| Spindle Speed | 2.5-250 RPM |
| Main Motor Power | 22kW |
| Overall Dimensions (L x W x H) | 6000x1860x1700mm (3m) |
| Net Weight (3m) | 11200/12000kg/12500kg |
Additional Information
- Rapid Feed Motor Power: 1.5kW
- Coolant Pump Power: 0.25kW
- Vertical Distance from Spindle Center to Installing Basis: 41mm
- Size of Tool Shank: 40x340mm
- Max Travel of Cross Slide: 720mm
- Swing Angle of Tool Post: ±90°
- Rapid Traverse of Longitudinal: 3740mm/min
- Rapid Traverse of Cross: 1870mm/min
- Rapid Traverse of Middle Tool Post: 935mm/min
