Heavy duty lathe CW61160
Inquire NowDescription
The Heavy Duty Lathe CW61160 is engineered for precision and durability, designed to meet the demands of heavy machining applications. With a maximum swing over the bed of Ф1400mm/1600mm and over the carriage of Ф1060mm/1260mm, this lathe offers ample capacity for a variety of workpieces. The spindle bore of Ф130mm allows for robust tooling options, while the spindle speed range of 2.5-250rpm ensures versatility in operation. Its powerful 22kw main motor guarantees consistent performance, making it the ideal choice for professional workshops.
Specifications
| Item | CW61140 / CW61160 |
|---|---|
| Max. swing diameter over bed | Ф1400mm/1600mm |
| Max. swing diameter over carriage | Ф1060mm/1260mm |
| Max. swing diameter over gap (optional) | Ф1930mm/2110mm |
| Effective length of gap (optional) | 590mm |
| Width of bed | 970mm |
| Effective length of gap | 590mm |
| Max. turned length | 1.5/2/3/4/5/6/7/8/10/12m |
| Max. length of workpiece | 1.3/1.8/2.8/3.8/4.8/5.8/7.8/9.8/11.8m |
| Max. weight of workpiece | 6000kg |
| Spindle bore | Ф130mm |
| Taper of bore | Metric Ф140m 1:20 |
| Number of speed | 24 (Normal) / 12 (Reverse) |
| Range of speed | 2.5-250rpm |
| Power of main motor | 22kw |
| Overall dimensions (L x W x H) | 6100x2080x2130mm |
| Net weight | 14100/15100kg |
Additional Information
For optimal operation and longevity, regularly maintain the lathe by checking the lubrication and ensuring all mechanical components are free from debris. The lathe’s specifications may be subject to change without notice.
