High Speed Fully Automatic Blow Moulding Machine 4 cavity
Inquire NowDescription
The HZ-HSP High Speed Fully Automatic Blow Moulding Machine is designed for efficiency and high output in the production of plastic bottles. Featuring a remarkable 4 cavity design, this machine can accommodate bottle sizes up to 2.25 liters. It is engineered for energy efficiency, as the preforms are heated while hanging, resulting in decreased electricity consumption. The machine’s innovative design allows for shorter center distances between preforms, which enhances blowing speed, making it an ideal choice for high-volume production environments. Additionally, it can be directly connected to a filling line, streamlining the manufacturing process. With a theoretical output of 6500 to 7500 bottles per hour, the HZ-HSP is a robust solution for modern bottling needs.
Specifications
| Feature | Details |
|---|---|
| Mould Capacity | Max bottle size: 2.25L |
| Energy Efficiency | Hanging-heated preforms |
| Blowing Speed | Higher due to shorter center distance |
| Output Rate | Theoretical output: 6500-7500 BPH |
| Connection | Can connect directly to filling line |
Additional Information
- Model: HZ-HSP
- 10 Cavity Version: Produces up to 16000 BPH
