High strength lace-up aramid fiber support grip
Inquire Now
These grips are woven of high strength ,non-conductive aramid fiber.
Are available for pulling single cable or cable bundles.
Their braided weave design adds strength and positive holding power.
Can be used in essentially all grip configurations.
Grips are corrosion resistant.
Aramid Fiber Support Grip–aramid fiber,lace-up
-
These grips are woven of high strength ,non-conductive aramid fiber.
-
Are available for pulling single cable or cable bundles.
-
Their braided weave design adds strength and positive holding power.
-
Can be used in essentially all grip configurations.
-
Grips are corrosion resistant.
| Part Number | Cable Diameter | Bale Length | Mesh Length |
Approx Break Strength |
| FAHS38L | 0.40-0.47″(10.2-12.0mm) | 6.0″(152.4mm) | 6.0″(152.4mm) | 500 lbs. |
| FAHS12L | 0.45-0.63″(11.4-16.0mm) | 7.0″(177.8mm) | 10.0″(254.0mm) | 500 lbs. |
| FAHS58L | 0.84-0.89″(21.3-22.6mm) | 8.0″(203.2mm) | 18.0″(457.2mm) | 900 lbs. |
| FAHS78L | 1.08-1.20″(27.4-30.5mm) | 13.0″(330.2mm) | 17.0″(431.8mm) | 900 lbs. |
| FAHS114L | 1.54-1.67″(39.1-42.4mm) | 8.0″(203.2mm) | 25.0″(635.0mm) | 1200 lbs. |
| FAHS158L | 1.98-2.04″(50.3-51.8mm) | 12.0″(304.8mm) | 25.0″(635.0mm) | 1600 lbs. |
| FAHS 214L | 2.35-2.36″(59.7-60.0mm) | 14.0″(355.6mm) | 26.0″(660.4mm) | 1600 lbs. |
