HONGSBELT HS-201A Flat top modular plastic conveyor belt
Inquire NowDescription
The HONGSBELT HS-201A Flat Top Modular Plastic Conveyor Belt is engineered for versatility and efficiency in various industries. This innovative conveyor belt combines advanced materials and design, making it a robust solution for both food and non-food applications. Its modular design allows for easy customization with side walls and cleats, ensuring seamless integration into existing conveyor systems.
With a pitch of 25.4mm and a thickness of 12.5mm, this conveyor belt is suitable for a minimum width of 75mm. It demonstrates exceptional strength and durability, boasting a maximum load capacity of up to 1.2 tons per square meter. The HS-201A operates effectively across a wide temperature range, from -40°C to 260°C, making it ideal for demanding environments. Its material composition, including PP, POM, PE, and PA, ensures it meets FDA and EU standards for safety and quality.
Specifications
| Attribute | Details |
|---|---|
| Type | HS-201A |
| Pitch | 25.4mm |
| Thickness | 12.5mm |
| Minimum Width | 75mm |
| Open Area | 0% |
| Approved | FDA, EU |
| Rod Diameter | 5.8mm |
| Flight | No |
| Side Guard | No |
| Curve | No |
| Material | PP, POM, PE, PA |
| Color | White, Blue, Gray, Nature, Dark-brown |
| Working Temperature | -40°C to 260°C |
| Sprocket Dimensions | Sprocket Size: 18T; Bore Size: square and round bore |
| Application |
|
| Advantages | Floating in water, food defrosting, over 10 times longer lifespan compared to traditional belts, maintenance-free, eco-friendly, easy to clean, high load capability. |
Additional Information
The HS-201A is designed for operational excellence, particularly in the food industry, where hygiene and safety are paramount. Its advantages include a maintenance-free feature and food-approved materials, ensuring both quality and compliance with stringent safety standards.
