HP3-3015 Shotcrete Sprayer

Inquire Now

Description

The HP3-3015 Shotcrete Sprayer is a highly efficient, electrically operated machine designed for superior wet shotcrete application. With an option for diesel drive, this sprayer is ideal for use in locations lacking electrical power. Its advanced features include a radio remote control system that enables the operator to manage all spraying functions from a safe distance, ensuring optimal focus on finish quality. The robust boom extends a remarkable 15.8 meters, while the machine boasts a theoretical capacity of 30 m³/h and a substantial 1000L additive IBC tank. Renowned for its reliability, ease of maintenance, and cost-effectiveness, the HP3-3015 is the go-to choice for tunneling projects.

Specifications

Attribute Unit Value
Machine Body Dimensions mm 7800 × 2740 × 3250
Gross Weight kg 16700
Power kW 75
Diesel Engine Power kW 74
Max Reach of Boom m 15.8
Spray Width m 25
Max Speed Km/h 20
Min. Ground Clearance mm 300
Working Pressure Mpa 24
Concrete Pipe Diameter mm Φ125-Φ90
Nozzle Diameter mm Φ50

Additional Information

The HP3-3015 Shotcrete Sprayer is equipped with features that enhance usability and efficiency, such as an adjustable spray lance movement and nozzle oscillation. Its construction parameters include a 4WD drive mode and a front-wheel steering system, ensuring excellent maneuverability in various work environments. The machine is designed for minimal maintenance and offers high reliability, making it an ideal choice for demanding tunneling applications.
