Hydraulic press brake
Inquire NowHydraulic press brake
Features:
1. With the function of brake
2. With adjustable work table
3. Extremely torsion-proof steel weldment
4. Reliable, highly accurate hydraulic system
5. Include replaceable top tools V-block and support table with stops
6. Table can be lifted through a chain driven by the main cylinder (optional)
Specification:
|
Item No. |
382009 |
|
Model |
HPB-1500 |
|
Capacity |
1500 kN |
|
Pressure |
30 mpa |
|
Piston travel/ Table travel |
250+405 mm |
|
Bending length |
1000 mm |
|
Bending thickness |
14 mm |
|
Motor power |
4 kW |
|
Table size |
460×980 mm |
|
N.W./G.W. |
1750/1980 kg |
|
Dimension for body |
184x75x225 cm |
|
Dimension for hydraulic station |
73x63x96 cm |
Standard accessories:
replaceable top tools V-block and support table with stops
Optional accessories:
Chain for table lifting by the main cylinder
