Industrial 3D texture automatic hybrid digital printer iLB1260
Inquire Nowbest choice of building decoration digital printing
Technical Parameter
| ILB1260 | |
| Printhead type | Industrial Piezoelectric Ceramics print head |
| printing size | 3000*1250mm |
| Color | CMYK/4colors |
| Ink | Certified ink only |
| Printhead Quantity | Max.36pcs |
| Printing Resolution | 720dpi×360dpi to 2880dpi×360dpi |
| Printhead Method | Single/Scanning print type |
| Max.Print Speed(3 pass) | 300-400m2/h(print time only) |
| Machine Dimensions | 8100×4000×2400MM(L*W*H) |
| Weight | 8T |
| Power Supply | 50/60HZ |
| Capacity | Max.50KW |
| Environment Requirement | Dust-free、far away from interference sources,lighting protection、no obvious vibration on the ground |
excellent color:
1、Magic Cube Max 6 Print head, 72000 nozzles (36 pcs)
2、6pl golden drop, perfect composition of precision and saturation
3、720NPI , easy for high-precision print quality
4、4-level grayscale, delicate and superimposed
5、UV ink, high applicability ,4-9ml/sqm of ink consumption
6、Equipped with standardized original customized inks, perfect color gamut, consistent color
7、Customized ICC color management,match PANTONE color coding
specialized technology
1、Nozzle compensation: avoid banding problem
2、Color enhancement: chromatic aberration smoothing, seamless print head stitching
3、Ease to order switch: flatness corrective mechanism, with vacuum adsorption, no shifting work
4、Productivity & Quality: single pass + multi-pass hybrid insertion point printing mode, combination of resolution and productivity
industrial standard
1、One-pass printing width : 1260mm
2、3×1.25m printing area，Cover most specifications of building materials
3、Printing on-demand, combination of traditional Processing and digital printing online production
4、Large discharge of 120ml/min circulation volume
5、Ink system closed-loop control, real-time monitoring, making ink pressure and flow rate stable
