Instant Electric Water Heater DR07B/C-J
Inquire Now
1. Instant Water Heater, 3 phases
2. Central hot water and heating supply
3. Mechanical control, Knob temperature adjustment
4. Multi shells and heating systems for choice
5. Could integrate 3 power levels of 18kW, 21kW and 24kW into one product
6. Energy saving and fast using
7. Dry heating and overheating protection, and can bear high water pressure
| Product Category | Instant Water Heater | ||
| Phase | 3 | ||
| Voltage | 380-400 V | ||
| Frequency | 50Hz/60 Hz | ||
| Power | 18 KW | 21 KW | 24 KW |
| Current | 28A | 32A | 37A |
| Working Pressure | 0.3-0.8MPa | ||
| Switch on Water Flow | 3.0L/MIN | ||
| Usage water flow | ≥8 L/MIN | ||
| Connection | G 1/2 | ||
| Wire Size | / | ||
| Waterproof Grade | IPX4 | ||
| Protection Category | I | ||
| Control Method | Mechanical | ||
| On/Off button | No | ||
| Working Indicator | Yes | ||
| Thermostatic | No | ||
| Temp. setting range | / | ||
| Overheat Protection | 75°C | ||
| Thermal Cut-out | 105°C | ||
| Certificate | CE | ||
| Net Weight | 3.06 KG | ||
| Grass Weight | 3.9 KG | ||
| Net Dimension | 23×11.5×39.5(Open wire-nichrome wire) 23x13x39.5(Other) |
||
| Unit Box Dimension | 25x13x41.5 CM | ||
| Master Carton Dimension | 28x53x44.5 CM (4B) | ||
| Loading Capacity 20Ft/40GP/40HQ | 360/724/800 | ||
| 1440/2896/3200 | |||
