Inverter IGBT AIR Plasma Cutting Machine LGK160(module IGBT)
Inquire NowDescription
The Inverter IGBT AIR Plasma Cutting Machine LGK160 is a state-of-the-art cutting device designed for versatility and efficiency. This advanced machine can cut using ordinary compressed air, making it suitable for a wide array of industries, including petroleum, chemical production, power supply, metallurgy, shipbuilding, and aerospace. Its ability to process various materials such as carbon steel, alloy steel, stainless steel, cast iron, aluminum, and copper sets it apart in the market.
Equipped with full bridge inverter technology utilizing dual IGBT and soft switch, the LGK160 maintains a highly stable welding current, even with fluctuating input voltage and varying arc lengths. Its portability, compact size, and lightweight design enhance its usability on-site. The machine ensures high efficiency and an impressive power factor, making it an energy-saving choice.
With a high duty cycle, the LGK160 supports continuous operation for extended periods. Its precise control system features a Pulse Width Modulator (PWM) controller that guarantees stability during operation. Excellent cutting performance is achieved through smooth edges, high precision, and minimal tension and deformation during cuts. Non-contact arc starting allows for instant and reliable arc ignition, effectively handling rusted and painted metals while being more environmentally friendly than traditional flame cutting machines.
Safety is paramount with the LGK160, featuring an integrity protection system that automatically safeguards against under-voltage, over-current, overheating, overloading, phase loss, and gas shortage. Its electromagnetic compatibility function ensures reduced power supply contamination, while a user-friendly design, including auto-locked and non-auto-locked options, significantly lessens the work intensity for welders.
Specifications
| Items | LGK160 |
|---|---|
| Input Power Voltage (V, Hz) | 380V±10% 50/60Hz |
| Rated Input Power Capacity (KVA) | 15 |
| No-load Voltage (V) | 350 |
| Output Current Adjustment Range (A) | 30-160 |
| Output Voltage Adjustment Range (V) | 144 |
| Duty Cycle (%) | 60 |
| No-load Consumption (W) | 100 |
| Efficiency (%) | 85 |
| Power Factor (COSΦ) | 0.93 |
| Arc Starting | No contact |
| Suggestion on Air Compressor Capacity (m³/min) | 0.36 |
| Weight (Kg) | 55 |
| Measurement (mm) | 650×330×620 |
| Insulation Class | F |
| Protection Class | IP21S |
| Max Cutting Thickness (mm) | 35 |
Additional Information
- Applicable Materials: Carbon Steel, Alloy Steel, Stainless Steel, Cast Iron, Aluminum, Copper
- Environmental Protection: More effective and efficient than traditional flame cutting machines
- User-friendly design with auto-locked and non-auto-locked functions
