Ironworker
Inquire NowDescription
The Ironworker is a versatile and powerful machine designed for a variety of metalworking tasks. Featuring a single sliding block structure driven by an oil cylinder, it boasts six standard working stations capable of performing multiple operations including punching, bending, shearing of round and square steel, and flat steel shearing. With additional accessories, it can extend its capabilities to channel steel shearing, round pipe cutting, and pipe bending.
Engineered for high precision and efficiency, the Ironworker’s design includes a polyurethane pressing and unloading device, which enhances the smoothness of operations and prolongs the lifespan of the die. Its robust crank and rocker mechanism enables reliable reciprocating movement, while the unique dovetail slot quick die change interface provides exceptional functionality and adaptability for various tasks. This machine is ideal for use in industries such as aviation, automotive, shipbuilding, metallurgy, electrical cabinets, steel frame construction, bridge building, and decoration.
Features
- One ram structure driven by an oil cylinder
- Six standard working positions
- Manual or foot pedestal cutting
- Capability for punching holes, positioning, and pressing for sheet metal
- Cutting functions for round steel, square steel, flat steel, and angle steel
- Optional tools for channel steel cutting and tube bending
- Quick-changing tools and automatic holding plate
- Interlocking and safety features
- High precision manufacturing with flexible operations
Specifications
| Item | Value | Unit | Standard/Optional tools |
|---|---|---|---|
| Size of working table | 536×370 | mm | |
| Max. pressing force | 1100 | KN | |
| Max. cutting plate size (Thickness×width) | 25×300, 20×450, 12×500 | mm | Cutting 20×450mm sheet available with machine |
| Not removing the blade for round (angle) steel, Max. cutting plate width is 400 mm | |||
| Max. cutting angle steel | 160×160×16 | mm | Available with machine |
| Max. punching hole force | 1100 | KN | |
| Max. punching hole size | Ф38×25 | mm | Punching Ф12×16mm hole available with machine |
| Cutting Round steel or Square steel | Round steel: Ф12～Ф50, Square steel: 12～35 | mm | Cutting Ф12～Ф30mm round steel available with machine |
| Cutting square steel, the blade is optional; Cutting Ф30～Ф50mm round steel, lower blade is optional. | |||
| Cutting channel steel | 50～200 | mm | Option |
| Sheet bending | 100×300 | mm | Option |
| Notching Position | Size of working table (left-right×front-back) | 485×510 | mm |
| Nominal force | 850 | KN | |
| Max. notching size (width×depth×thickness) | 100×150×10 | mm | Available with machine |
| Motor power | 15 | kW | |
| Overall dimensions (L×W×H) | 2300×1690×1087 | mm | |
| Weight | 2800 | kg | |
Additional Information
The Ironworker is designed for high manufacturing precision, making it suitable for various industries requiring efficient and flexible operations.
