JC200T-B
Inquire NowDescription
The JC200T-B is a marvel of engineering designed for enthusiasts who seek performance and reliability. This advanced motorcycle features a single-cylinder, water-cooled engine equipped with Electronic Fuel Injection (EFI) and a four-valve DOHC system, ensuring compliance with Euro IV emissions standards. The innovative modular and lightweight design enhances reliability while making maintenance a breeze. With optimized components like a short piston and crankshaft, this model boasts a remarkable 20% weight reduction, resulting in improved thermal efficiency and reduced power loss. Experience superior performance with its four-valve DOHC configuration, which maximizes intake and exhaust flow for stronger power delivery.
The three-point support transmission shaft technology minimizes noise and wear during high-speed, high-torque operations, while the platform net honing technology in the cylinder block ensures excellent lubrication and reduced vibration. Enjoy a smooth ride with the eccentric crankshaft connecting rod mechanism, which provides stability, low fuel consumption, and enhanced comfort for long-distance travel.
Specifications
Feature | 200CC | 125CC |
---|---|---|
Overall Dimensions (LxWxH) (mm) | 2080 x 725 x 1345 | |
Wheelbase (mm) | 1380 | |
Dry Weight (kg) | 160 | |
Max Load (kg) | 160 | |
Max Speed (km/h) | 120 | 110 |
Economic Fuel Consumption (L/100km) | ≤ 2.8 | ≤ 2.3 |
Engine Type | 1-cylinder, 4-stroke, DOHC, 4-valve, water-cooled, EFI | |
Bore (mm) x Stroke (mm) | 63.0 x 60.5 | 58 x 47 |
Displacement (cc) | 188.6 | 124.2 |
Compression Ratio | 12.1:1 | |
Max Power (kw/r/min) | 14.1 / 8250 | 10.5 / 9750 |
Max Torque (N.m/r/min) | 16.5 / 6500 | 11.2 / 8000 |
Ignition | E.C.U | |
Starter | Electric starting | |
Transmission | CVT | |
Suspension (Fr./Rr) | Hydraulic fork / Spring Shock Absorber | |
Tires (Fr./Rr) | 100/80-16 / 120/80-16 | |
Brakes (Fr./Rr) | Disc/Disc ABS | |
Fuel Tank Capacity (L) | 8 | |
Battery | 12V10Ah |
