JD1200
Inquire NowPOWERFUL,HIGH OUTPUT,EASY HANDLING AND MAINTAINING.SONCAP APPROVED
|
Specification |
|||
|
GENERATOR |
Model |
JD1000 |
JD1200 |
|
Type |
Single-Phase |
||
|
Voltage Regulate |
Capacitor |
||
|
Frequency Hz |
50/60 |
||
|
Rated AC Voltage (V) |
110/120/220/240 |
||
|
Rated AC Output (KVA) |
1.0 |
1.1 |
|
|
Peak AC Output (KVA) |
1.1 |
1.2 |
|
|
Power Factor COSφ |
1.0 |
||
|
ENGINE |
Model |
JF154 |
|
|
Type |
4-stroke, single cylinder with Air-cooled |
||
|
Bore x Stroke (mm/inch) |
54×38.5/2.13×1.52 |
||
|
Displacement (ml) |
86.5 |
||
|
Max. output (HP/rpm) |
2.4/3600 |
||
|
Fuel |
Unleaded Gasoline |
||
|
Fuel Tank Capacity (L/gal) |
5/1.3 |
||
|
Oil |
SF or Higher Grade |
||
|
Oil Capacity (L/gal) |
0.4/0.11 |
||
|
Ignition system |
C.D.I. |
||
|
Starting System |
Recoil and hand-operated |
||
|
Operating Noise Level (7m) dB(A) |
67 |
||
|
STANDARD FEATURES |
Fuel gauge |
0 |
0 |
|
Engine Switch |
0 |
0 |
|
|
Voltmeter |
0 |
0 |
|
|
AC Circuit Breaker |
0 |
0 |
|
|
AC Socket |
0 |
0 |
|
|
Pilot Light |
0 |
0 |
|
|
DC Output |
0 |
0 |
|
|
DC Circuit Breaker |
0 |
0 |
|
|
PACKAGE DIMENSIONS |
Dimensions L×W×H (mm/inch) |
457×363×390/18.0×14.3×15.4 |
|
|
Net Weight (kg/lbs) |
30/66 |
||
|
Gross Weight (kg/lbs) |
31/68.2 |
||
|
20/40FT unit |
475/955 |
||
NOTE:0=with +=as request -= without Specifications subject to change without notice
