Jft-10 series grating ruler
Inquire NowDescription
The JFT-10 Series Grating Ruler is a precision measurement tool designed for high accuracy and reliability in various applications. This absolute grating ruler offers resolutions of 2.5 nm, 5 nm, and 10 nm, making it ideal for tasks requiring meticulous measurement. With a motion velocity of up to 180 m/min and protection levels of IP53 and IP64, it is built to withstand demanding environments while providing consistent performance.
In addition to its remarkable precision, the incremental grating ruler variant extends its effective range from 100 mm to over 3200 mm, accommodating a wide range of measurement needs. It features multiple output signals, including TTL, HTL, and RS422, ensuring compatibility with various systems. The ruler’s design emphasizes both durability and ease of use, making it an essential tool for professionals in engineering, manufacturing, and research.
Specifications
| Attribute | Details |
|---|---|
| Communications Agreements | BISS-c, DRIVE-CLIQ |
| Resolution | 2.5 nm, 5 nm, 10 nm |
| Motion Velocity | ≤180 m/min |
| Protection Level | IP53, IP64 |
| Attribute | Details |
|---|---|
| Effective Range (mm) | 100-3200, 50-1000, 100-1500, 50-500, >3200, 50-550 |
| Output Signal | TTL, HTL, RS422 |
| Zero Reference Point | One per 50 nm (50 line pair/nm) |
| Gate Distance (mm) | 0.02 (50 mm), 0.04 (25) |
| Resolution (um) | 10.5, 1, 0.5 |
| Accuracy (um) | ±10, ±5, ±3 |
| Response Speed (m/min) | 30-60 (resolution 1 µm, 0.5 µm), 120 (resolution 5 µm, 10 µm) |
| Operating Temperature (℃) | 0-50 |
| Storage Temperature (℃) | -40-55 |
Additional Information
This grating ruler is engineered for optimal performance in precision applications. Ensure to operate within the specified temperature ranges for best results.
