JSM400 type concrete mixer
Inquire NowDescription
The JSM400 type concrete mixer is a robust and efficient solution for mixing concrete, designed to meet the demands of construction professionals. With a feeding capacity of 640 liters and a discharge capacity of 400 liters, this mixer ensures optimal productivity with a maximum output of 14 cubic meters per hour. The JSM400 features a durable design with a mix bobbin no-load speed of 15 r/min, allowing for thorough and consistent mixing of materials. Its hopper operates at an average speed of 0.3 m/s, facilitating quick loading. This concrete mixer is powered by high-performance motors, ensuring reliability and efficiency on the job site.
Specifications
| Attribute | Details |
|---|---|
| Model | JZM400 |
| Feeding Capacity | 640 L |
| Discharge Capacity | 400 L |
| Productivity | 14 m³/h |
| Mix Bobbin No-load Speed | 15 r/min |
| Aggregate Maximum Diameter | 60 mm |
| Hopper Average Speed | 0.3 m/s |
| Mixing Motor Type | b5 Y132s – 4 |
| Mixing Motor Power | 5.5 kW |
| Lifting Motor Model | YEZ32-4 |
| Lifting Motor Power | 4.5 kW |
| Water Pump Motor Type | 40 JDB – 12 |
| Water Pump Motor Power | 0.55 kW |
| Tire Size | 6.50-16 |
| Overall Dimensions (L x W x H) | 3800 x 2050 x 2690 mm |
| Weight | 1990 kg |
