Description
The KB6500-W is a robust and efficient single-cylinder generator designed for versatility and reliability. Featuring a 4-stroke OHV engine with a 25° air cooling system, this generator is ideal for various applications, providing dependable power wherever you need it. With a rated output of 5.0 to 5.3 kW and a maximum output of up to 5.8 kW, it caters to both light and heavy-duty tasks. The KB6500-W operates at a rated voltage of 110/220V and a frequency of 50/60 Hz, making it suitable for diverse environments.
Specifications
| Attribute | Details |
|---|---|
| Type | Single Cylinder, 4-Stroke, OHV 25°, Air Cooling |
| Rated Frequency (Hz) | 50/60 |
| Rated Voltage (V) | 220 / 110/220 |
| Rated Amperage (A) | 23 / 48/24 |
| Rated Output (KW) | 5.0 / 5.3 |
| Max Output (KW) | 5.5 / 5.8 |
| Engine Model | KB188FE |
| Power Factor | 1.0 |
| Gross Weight (kg) | 82 |
| Net Weight (kg) | 79 |
| Dimensions (mm) | 695 × 525 × 575 |
| Container Loading (20GP/40HQ) | 140 / 280 |
Additional Information
For optimal performance, ensure that the generator is regularly maintained and serviced. Follow the manufacturer’s guidelines for operation and safety precautions.
