KD20V171ZL
Inquire Now–
| Model | KD20V171ZL |
| Type | 90-degree V-shaped |
| Chamber type | Shallow ω |
| Turbocharging type | Exhausted gas turbine turbocharger |
| Cooling type | Forced closed water-cooled |
| Intake cooling type | Water-Air intercooler |
| Bore×stroke(mm) | Φ171×210 |
| Compression ratio | 15.5:1 |
| turbocharge ratio | 3.3 |
| Flywheel shell（SAE） | 00 |
| Generator disc（ADE） | 21 |
| Fuel consumption /speed〔g/(kW·h)〕 | 186+5%/1500 195+5%/1800 |
| Displacement（L） | 96.45 |
| Rated power/rated speed | 2705/1500 3012/1800 |
| Max. power/rated speed | 2976/1500 3313/1800 |
| Min. adjustable speed(zero load)（r/min） | ≤650 |
| Rotation direction(face to the flywheel) | Anticlockwise |
| Valve clearance(cold)（mm） | Intake valve0.20 exhaust valve 0.50 |
| Starting system | Electric starter |
| Lubrication system | Pressure splashed |
| Overall dimension（L×W×H）（mm） | 3627×1545×1965 |
