KEXINDA CHINA Colorful Zinc Sheet 828 Glazed Tile Roofing Panel Roll Forming Machine
Inquire NowThe KEXINDA CHINA Colorful Zinc Sheet 828 Glazed Tile Roofing Panel Roll Forming Machine is a state-of-the-art solution designed for manufacturers looking to produce high-quality roofing panels efficiently. This machine is engineered to process various materials including color steel plates, galvanized sheets, and aluminum coils, making it versatile for different applications. With a feeding width of 1000mm and a productivity rate of 8-12m/min, it meets the demands of both large-scale and small-scale production. The robust construction features 11 roller stations and utilizes 45# steel for durability, ensuring a long service life.
| Attribute | Details |
|---|---|
| Name | Botou colorful zinc sheet 828 glazed tile roofing panel roll forming machine |
| Suitable to process | Color steel plate, galvanized sheet, aluminum coils, etc. |
| Width of the feeding material | 1000mm |
| Roller station | 11 rows |
| Thickness of feeding material | 0.3-0.8mm |
| Power Supply | 380V, 3-Phase, 50Hz |
| Productivity | 8-12m/min |
| Rollers’ material | 45# steel |
| Diameter of shaft | 75mm |
| Roller Diameter | 80mm |
| Wall thickness of main forming machine | 14mm steel plate |
| Main forming machine body | 300 mm H steel |
| Motor power | 4+3kw |
| Cutter Standard | GCr12 |
| Size | 7500*1500*1600mm |
| Weight | About 3.5T |
| Custom | According to customer’s requirements |
This machine comes equipped with various components including a man-made uncoiler, roll forming machine, computer control system, hydraulic control system, and cutting tools. It is widely used in industrial factories, civilian buildings, warehouses, and easy steel building manufacturing, boasting features such as an attractive appearance and durability.
