KEYPOWER Resistive Load Bank 300 kw
Inquire Nowindependent research and development
Product Details >>>>>>>>
| KEYPOWER GENERATOR TESTER SPECIFICATIONS | ||||
| Measurement | Range | Accuracy | Resolution | Overload |
| Voltage (V) | 10.0~500.0V | ± (0.4% reading+0.1%range) | 0.1V | 600V |
| Current (A) | 0.030~5.000A | ± (0.4% reading+0.1%range) | 0.001A | 6A |
| Power |
According to volt range & current range |
Power factor =1.0 | <200W 0.1W | |
| ± (0.4% reading+0.1% range) | ≥200W 1W | |||
| Power factor =0.5 | ≥2kW 10W | |||
| ± (0.8% reading+0.2% range) | ||||
| Power Factor | 0.20~1.00 | ±0.02 | 0.001 | |
| Frequency | 45~65Hz | ±0.2Hz | 0.01Hz | |
| Running Time | 99h59m | ±2min/hour | 1 minute | |
| Energy (kWh) |
99999kWh | Power factor= 1.0 | 0.001kwh | |
| ± (0.4% reading+0.1% range) | ||||
| Power factor=0.5 | ||||
| ± (0.8% reading+0.2% range) | ||||
|
Harmonic Analysis (%) |
2-50 times and total harmonic |
|||
| Models You Can Choose | |||||||||
| Model |
Testing capacity |
Type of load |
Duty |
Cooling system |
Phase |
Rated Testing Voltage |
Rated Frequency |
Dimensions (L*W*H) (mm) |
Weight (kg) |
| KPLB-100 | 0 – 100 kw |
Resistive or Reactive, PF = 1.0 or 0.8 |
Continuous |
Industrial grade axial fan |
Available at both single and three phase |
110-480 VAC |
50/60 Hz | 960*1060*1400 | 350 |
| KPLB-200 | 0 – 200 kw | 1560*1310*1650 | 850 | ||||||
| KPLB-300 | 0 – 300 kw | 1690*1440*1750 | 1100 | ||||||
| KPLB-400 | 0 – 400 kw | 1900*1600*1900 | 1250 | ||||||
| KPLB-500 | 0 – 500 kw | 1900*1600*1900 | 1400 | ||||||
| KPLB-600 | 0 – 600 kw | 2100*1730*2000 | 1550 | ||||||
| KPLB-700 | 0 – 700 kw | 2100*1730*2000 | 1650 | ||||||
| KPLB-800 | 0 – 800 kw | 2400*2030*2100 | 2010 | ||||||
| KPLB-1000 | 0 – 1000 kw | 2400*2030*2100 | 2250 | ||||||
| KPLB-1300 | 0 – 1300 kw | 3500*2270*2150 | 3070 | ||||||
| KPLB-1400 | 0 – 1400 kw | 3500*2270*2150 | 3150 | ||||||
| KPLB-1500 | 0 – 1500 kw | 3500*2270*2150 | 3300 | ||||||
| KPLB-1600 | 0 – 1600 kw | 6058*2438*2591 | 6000 | ||||||
| KPLB-2000 | 0 – 2000 kw | 6058*2438*2591 | 7360 | ||||||
| KPLB-2200 | 0 – 2200 kw | 6058*2438*2591 | 7700 | ||||||
| KPLB-2500 | 0 – 2500 kw | 6058*2438*2591 | 8100 | ||||||
Specifications
100-2000KW Load Bank for Generator Load Test:
1.Premium components
2.Durable and reliable
3.Easy to transport
Load bank is a simulating load test equipment used for generators,
UPS, battery banks etc power systems load test.
1. Resistive type of load, PF = 1.0. Stainless steel sheathed elements manufactured from high grade magnesium oxide.
2. Rated testing voltage: AC 3P4W, 110-480V 50/60 Hz.
3. Cooling mode: Forced air-cooled, fans mounted on the side of the load bank blow horizontally. Testing power or external utility power supply for fans.
4. Working mode: Load step control
Total testing capacity ranges from 0kw to the max consisting of 10kw, 20kw, 50kw, 100kw load setting switches plus a 0-10kw fine-tuning knob. From 0kw to the max, any load combination is achievable. Load step resolution is 10kw.
5. Load bank features world-famous components to ensure reliable performance and longer service life including:
SCHNEIDER contactors.
Siemens switches, knobs and indicators.
ABB Circuit breakers.
OMRON intermediate relays.
PHOENIX terminal blocks.
6. Parameter measuring accuracy grade: 0.3
7. Load control accuracy: ± 5%.
8. Load bank protections: Over heating protection, cooling fans failure protection and over load protection with alarm.
9. Control mode: Two control modes available:
A)Local manual control;
B)Optional: Manual control via a remote control panel (max control distance is 30m).
10. Parameter display and measurement:
Control panel contains a LOVATO Multifunction Electricity Meter displaying voltage, current, load power, reactive power, apparent power, power factor, frequency etc.
(Optional: A professional generator tester displays and measures all sorts of steady, dynamic parameters as well as harmonic wave, can be connected to a PC for data recording and test report printing). ”
11. Operating environment:
Altitude: ≤ 3000m above sea level. Ambient temp: -10~+50 ℃
Relative humidity: ≤ 80% ventilated environment without explosive or corrosive dust. Not allowed to use in rainy outdoor environment.
Any question, please contact me directly.
