Korlen New Type Isolator DIN Rail Mounting
Inquire NowDescription
The Korlen New Type Isolator DIN Rail Mounting is an essential component designed for effective electrical isolation in various applications. This robust isolator is engineered to handle rated voltages of 240/415V, making it suitable for diverse electrical systems. With options for rated currents ranging from 32A to 125A and configurations available in 1P, 2P, 3P, or 4P, it provides flexibility for installation in different environments. The isolator features high impulse withstand voltage, durable mechanical life, and a protection degree of IP20, ensuring reliability under challenging conditions.
Specifications
| Attribute | Value |
|---|---|
| Rated voltage Ue | 240/415V |
| Rated current le | 32, 40, 50, 63, 80, 100, 125A |
| Poles | 1P, 2P, 3P, 4P |
| Rated frequency | 50/60Hz |
| Rated impulse withstand voltage (1.2/50)Uimp | 4,000V |
| Rated short-time withstand current lcw | 12le, 1s |
| Rated making and breaking capacity | 3le, 1.05Ue, cos Φ =0.65 |
| Rated short circuit making capacity | 20le, t=0.1s |
| Dielectric test voltage at ind. Freq. For 1min | 2.5kV |
| Insulation voltage Ui | 500V |
| Pollution degree | 2 |
| Utilization category | AC-22A |
| Electrical life | 1,500 |
| Mechanical life | 8,500 |
| Protection degree | IP20 |
| Storage temperature | -25°C to +70°C |
Additional Information
Installation is simplified with terminal connections for cable and pin-type busbar, accommodating a terminal size of 50mm². The tightening torque required for installation is 2.5 N*m. For shipping, products are typically dispatched via sea from Ningbo, with options for express shipping through UPS, DHL, FedEx, or TNT. A drop shipping service is provided, and lower declaration values can be arranged to facilitate tax-free imports.
