Latching electromagnetic closing opening shunt coil solenoid trip coil for Circuit breaker
Inquire NowDescription
The Latching Electromagnetic Closing Opening Shunt Coil Solenoid Trip Coil is a vital component designed for the efficient operation of circuit breakers, specifically tailored for type ZN63 and VS1 handcart models. This advanced solenoid mechanism is engineered to control the closing function of circuit breakers within control modules, ensuring reliable operation under various conditions.
This closing coil operates through a core-driven system, comprising components such as the coil, moving core, mounting base, and return spring. Its precision manufacturing guarantees exceptional durability, high performance, and resistance to high temperatures, making it an ideal choice for demanding applications in electrical systems.
With its dependable design, this solenoid not only facilitates the closing operation when charged but also prevents unintended closures when uncharged, thereby enhancing the safety and reliability of circuit operations.
Specifications
| Attribute | Details |
|---|---|
| Type | Shunt Coil Solenoid Trip Coil |
| Application | ZN63 and VS1 Circuit Breakers |
| Functionality | Controls closing operations; retracts when charged and pops up when uncharged |
| Durability | High temperature resistance, reliable performance |
Additional Information
For optimal performance, ensure proper installation and regular maintenance of the solenoid. This will contribute to its longevity and reliability in critical electrical systems.
|
|
