Description
The LAY4-ED21 industrial joystick handle is designed for precision control and reliability in various applications. This versatile pushbutton switch is engineered to handle AC voltages up to 660V/50Hz or 60Hz and DC voltages below 400V, making it suitable for controlling signals and interlocking purposes. Constructed with a robust zinc alloy body and high-grade anti-flame plastic, it ensures durability and safety. The internal contacts utilize a special silver alloy, offering exceptional resistance to electrical erosion. Additionally, the joystick handle includes a signal lamp series that supports electrical appliances up to 380V/50Hz, ideal for indicating, warning, and emergency signals. All products meet GB/T14048.1 and IEC60947-5-1 standards, and are CE, ISO9001, RoHS, and UL certified.
Specifications
| Main Technical Parameter | Button (Basic Technical Parameter) | Signal Lamp (Basic Technical Parameter) |
|---|---|---|
| Rated Insulation | AC 600V (50Hz/60Hz) | Insulation Resistance |
| Conventional Heating Current | 10A | Contact Resistance |
| Insulation Resistance | ≥50MΩ | Pf Withstand Voltage |
| Contact Resistance | ≤25MinΩ | Voltage Wave |
| Mechanical Life | 100×10000 (Pushbutton) | 50×10000 (Selector Switch) |
| Electrical Life | 500×10000 (Pushbutton) | 25×10000 (Selector Switch) |
| Continuous Working Life | 10x10000h | |
Additional Information
- Brightness: 60cd/m²
