LAY4-EJ21 industrial joystick handle plastic or pushbutton switch
Inquire NowDescription
The LAY4-EJ21 industrial joystick handle is a versatile and robust control mechanism, designed for high-performance applications. Made from durable plastic and featuring a pushbutton switch, this joystick is ideal for controlling circuits of AC voltage up to 660V/50Hz or 60Hz, as well as DC voltage below 400V. It’s perfect for signal control and interlocking purposes, making it an essential component for various industrial machinery and equipment.
The joystick’s main body is crafted from zinc alloy and high-grade anti-flame plastic, ensuring reliability and safety in demanding environments. The contacts utilize a special silver alloy, providing exceptional resistance to electrical erosion and ensuring long-lasting durability. This product conforms to GB/T14048.1 and IEC60947-5-1 standards and is CE, ISO9001, ROHS, and UL certified for quality assurance.
Specifications
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Rated insulation | AC 600V (50Hz/60Hz) | Insulation resistance | ≥50MΩ |
| Conventional heating current | 10A | Contact resistance | ≤25MinΩ |
| Pf withstand voltage | AC 2.5KV/min | Voltage wave | ±20% |
| Mechanical life | 100×10000 pushbutton | Electrical life | 500×10000 pushbutton |
| Brightness | 60cd/m² | Continuous working life | 10x10000h |
Additional Information
- Ideal for indicating signals, warning signals, and emergency signals.
- Meets stringent safety and performance certifications.
