LAY4-EL31 plastic green convex head push button convex push button

Inquire Now

Description

The LAY4-EL31 Green Convex Push Button is expertly designed for controlling circuits of AC voltage up to 660V at 50Hz or 60Hz, and DC voltage below 400V. This reliable push button is an essential component for signal control and interlocking applications. Its durable construction features a main body made from zinc alloy and high-grade anti-flame plastic, ensuring longevity and safety. The special silver alloy contacts enhance the device’s resistance to electrical erosion, making it suitable for a variety of electrical appliances, including indicating, warning, and emergency signals. All products comply with GB/T14048.1 and IEC60947-5-1 standards, and are fully CE, ISO9001, ROHS, and UL certified.

Specifications

Parameter Push Button Signal Lamp
Rated Insulation AC 600V (50Hz/60Hz) Insulation Resistance
Conventional Heating Current 10A Contact Resistance
Insulation Resistance ≥50MΩ Pf Withstand Voltage
Contact Resistance ≤25MinΩ Voltage Wave
Mechanical Life 100×10000 pushes Brightness
Electrical Life 500×10000 pushes Continuous Working Life

Additional Information

  • Dimensions: Standard size suitable for most electrical panels.
  • Easy installation and maintenance.
  • Ideal for industrial and commercial applications.


LAY4-EL31 PART_副本.jpg
