LAY5-EJ21 or three position latching 24 volt push button switch
Inquire NowDescription
The LAY5-EJ21 is a versatile three-position latching 24-volt push button switch designed for reliable control in various electrical applications. This switch excels in controlling circuit operations for AC voltages up to 660V at 50Hz or 60Hz, and DC voltages below 400V. It effectively manages signal and interlocking functions, making it an essential component in machinery and control systems.
Constructed from durable zinc alloy and high-grade anti-flame plastic, the LAY5-EJ21 features a special silver alloy contact that ensures excellent resistance against electrical erosion. Additionally, the integrated signal lamp series is compatible with electrical appliances operating at AC voltages up to 380V at 50Hz, and DC voltages below 380V, providing effective indication and warning signals. Furthermore, this product complies with GB/T14048.1 and IEC60947-5-1 standards and is certified with CE, ISO9001, ROHS, and UL, ensuring quality and safety.
Specifications
| Parameter | Push Button | Signal Lamp |
|---|---|---|
| Rated Insulation | AC 600V (50Hz/60Hz) | Insulation Resistance |
| Conventional Heating Current | 10A | Contact Resistance |
| Insulation Resistance | ≥50MΩ | Pf Withstand Voltage |
| Contact Resistance | ≤25MinΩ | Voltage Wave |
| Mechanical Life | 100×10,000 pushbutton | Brightness |
| Electrical Life | 500×10,000 pushbutton | Continuous Working Life |
Additional Information
- Ideal for machinery control and electrical applications
- Robust design ensures long-lasting performance
- Certifications: CE, ISO9001, ROHS, UL
