LC4 AC Contactor

APPLICATION
LC1-D AC Contactor is suitable for using in the circuits up to the rated voltage 660v,AC 50hz or 60hz,rated current up to 95A,for making ,breaking frequently starting &machine-interlocking device etc,it becomes the dalay contactor,mechanical interlocking contactor,star-delta starter.with the thermal relay,it is combined into the electromagnetic starter.The contactor is produced according to IEC947-2,VDE0660&BS5442

SPECIFICATION

Type		LC1-D09	LC1-D12	LC1-D18	LC1-D25
Rated workingcurrent (A)	AC3	9	12	18	25
Rated workingcurrent (A)	AC4	3.5	5	7.7	8.5
Standardpower ratingsof 3-phase motors 50/60Hz incategory AC-3	220/230V	2.2	3	4	5.5
	380/400V	4	5.5	7.5	11
	415V	4	5.5	9	11
	500V	5.5	7.5	10	15
	660/690V	5.5	7.5	10	15
Rated heat current (A)		20	20	32	40
Electrical life	AC3 (x104)	100	100	100	100
Electrical life	AC4 (x104)	20	20	20	20
Mechanical life (x104)		1000	1000	1000	1000
Number of the contacts	3P+NO
Number of the contacts	3P+NC
