Lipo battery 3.7V 7.4V Lithium ion battery LIP503450-900mAh with PCB
Inquire NowDescription
Introducing the Lipo Battery 3.7V 7.4V Lithium-Ion Battery LIP503450-900mAh with PCB, engineered for optimal performance and reliability. This compact battery is perfect for powering a variety of devices, from drones to handheld electronics. With a nominal capacity of 900mAh, this lithium-ion battery ensures long-lasting energy while maintaining a lightweight profile, weighing just 17.5g. Its advanced PCB design provides essential protection against overcharging and short circuits, making it a safe choice for various applications.
Specifications
| Attribute | Details |
|---|---|
| Model | 7.4V 2s LIP503450-900mAh |
| Dimension | 10 x 34 x 50 mm |
| Nominal Capacity | 900 mAh |
| Nominal Voltage | 3.7V (per cell) |
| Charge Voltage | 4.2V (per cell) |
| Cut Off Voltage | 3.0V (per cell) |
| Max Charge Current | 450mA (0.5C) |
| Max Discharge Current | 900mA (1C) |
| Cell Resistance | ≤60 mΩ |
| Cell Weight | 17.5g |
| Certification | UL, PSE, CE, KC, BIS, CQC, UN38.3, IEC62133 |
| Storage Temperature | -20±45°C (Less than 30 days) |
| Operating Temperature | -20°C to 60°C |
| Cycle Life | (500 cycles) ≥80% of Initial Capacity (0.2C) |
| Warranty | 12 months |
Additional Information
This lithium-ion battery is designed for both durability and performance. Ideal for various applications, it guarantees a stable output and efficient energy management. To maximize the battery’s lifespan, adhere to the recommended charging practices and store it in a cool, dry place. With a warranty of 12 months, customers can trust in the quality and longevity of this product.
