Lithium iron phosphate battery
Inquire Now
■High safety and power density
■Rackmounted and modular design
■RS232/RS485/CAN communication port
■Support multiple modular battery packs for parallel
■BMS battery management system
■More than 3000 times of charging and discharging
Main features
■High safety and power density
■Rackmounted and modular design
■RS232/RS485/CAN communication port
■Support multiple modular battery packs for parallel
■BMS battery management system
■More than 3000 times of charging and discharging
Application
UPS/communication system/base station power supply
Parameters for Li-ion rechargeable battery
|
Battery module |
||
|
Model |
A4850 |
A48100 |
|
Capacity |
48V50Ah |
48V100Ah |
|
Electric core |
3.2V 50Ah |
3.2V 100Ah |
|
Charging voltage max. |
56.8V |
54.75 |
|
Voltage at end of |
44.0V |
37.5-42.0V |
|
Standard charge |
10A |
20A |
|
Standard discharge |
10A |
20A |
|
Maximum |
50A |
100A |
|
Maximum |
50A |
100A |
|
Monitoring |
BMS battery management system |
|
|
Operation |
Charge : 0~45℃ |
Charge : 0~45℃ |
|
Charge :-10℃ ~ 60℃ |
Discharge : -20~55℃ |
|
|
Dimension |
442*440 *131mm |
442*440*261 mm |
|
Weight |
22kg |
48kg |
Note：
1, Because the products are continuously improved, please contact the company or dealer to inquiry the latest specification.
