LONGFLEX CHAIN FD 431 CY
Inquire NowDescription
The LONGFLEX CHAIN FD 431 CY is a specialized signal control cable designed for use in low voltage systems across various automation equipment. It is particularly suited for CNC machines, engraving machines, woodworking machines, and other production lines where frequent movement is required. Engineered for durability and flexibility, this cable excels in drag chain applications, ensuring reliable performance in dynamic environments.
Specifications
| Technical Parameter | Details |
|---|---|
| Temperature Range | Fixed Application: -40°C~80°C Mobile Application: -5°C~70°C |
| Test Voltage | 2000V/min (AC) |
| Insulation Resistance (20°C) | ≥10MΩ.km |
| Rated Voltage | 30V |
| Minimum Bending Radius | Fixed Application: 4D (D=cable diameter) Mobile Application: 7.5D (D=cable diameter) |
| Technical Certification | UL2464 |
| Application of Drag Chain | 3~8 million times |
| Conductor | Fine stranded bare copper, according to IEC 60228/VDE 0295 class 6 |
| Insulation | PVC |
| Insulation Color | According to DIN 47100 |
| Jacket | PVC |
| Color | Grey (similar to RAL 7001) |
Additional Information
- Flame resistance according to IEC 60332-1
- Excellent flexibility
- Small bending radius
- Good oil resistance
