LONGFLEX MC 817 P
Inquire NowDescription
The LONGFLEX MC 817 P is a versatile control cable designed to excel in demanding environments such as tool machines, conveyor belts, production lines, and air-conditioning systems. Its robust construction allows it to perform reliably in greasy and wet conditions, making it an ideal choice for both indoor and outdoor applications, even in low temperatures. This cable is engineered for both fixed installations and non-sustained shuttle bending movements, ensuring maximum flexibility and durability.
Specifications
| Parameter | Value |
|---|---|
| Temperature Range (Fixed Application) | -50°C to 90°C |
| Temperature Range (Occasional Movement) | -40°C to 80°C |
| Test Voltage | 3000V |
| Insulation Resistance (20°C) | ≥20MΩ.km |
| Rated Voltage | 300/500V |
| Minimum Bending Radius (Fixed Application) | 4D (D = cable diameter) |
| Minimum Bending Radius (Occasional Movement) | 12.5D (D = cable diameter) |
| Conductor | Fine stranded tinned bare copper (IEC 60228/VDE 0295 class 5) |
| Insulation | TPE |
| Jacket | PUR (Grey, similar to RAL 7001) |
Additional Information
- Flame Resistance: Complies with IEC 60332-1
- Flexibility: Features a small bending radius and exceptional flexibility
- Halogen Free: Environmentally friendly design
- Oil Resistance: Extremely resistant to oil and abrasion
- Anti-Hydrolysis: Designed to withstand hydrolysis effectively
