LOVOL E SERIES 504 TRACTOR
Inquire Now
LOVOL E504 tractor, narrow wheelbase type, is a product for farmland (dry field, paddy field), vineyard, orchard, greenhouse planting, animal farm and other multi-functional applications;
QuanChai 495 engine, satisfies the Euro II emission standard; Doosan D18 engine as an option to meet the emission standard of Tier 4F; Torque reserve coefficient ≥25%, traction force up to 9.5kn; Synchronizer 8F+8R gear, easy to shift; Body appearance upgrade, high handling comfort.
The use of famous brand clutch, American Actuant instrument, LOVOL central piercing cylinder front axle; Rear wheeltrack 960mm, suitable for orchard operation; Multiple tire options; optional common wheeltrack and narrow wheeltrack models; optional internal and external air filter, upper and lower exhaust; optional single pipeline/double pipeline air brake
Dual-way hydraulic output; Category I three-point hitch, double cylinder high pressure lifter, maximum lifting force up to 8.27 KN; optional PTO rotation speed 540/720/1000, swing drawbar can be equipped with a variety of implements to meet the needs of different operations.
-
LOVOL E504 tractor, narrow wheelbase type, is a product for farmland (dry field, paddy field), vineyard, orchard, greenhouse planting, animal farm and other multi-functional applications;
-
QuanChai 495 engine, satisfies the Euro II emission standard; Doosan D18 engine as an option to meet the emission standard of Tier 4F; Torque reserve coefficient ≥25%, traction force up to 9.5kn; Synchronizer 8F+8R gear, easy to shift; Body appearance upgrade, high handling comfort.
-
The use of famous brand clutch, American Actuant instrument, LOVOL central piercing cylinder front axle; Rear wheeltrack 960mm, suitable for orchard operation; Multiple tire options; optional common wheeltrack and narrow wheeltrack models; optional internal and external air filter, upper and lower exhaust; optional single pipeline/double pipeline air brake
-
Dual-way hydraulic output; Category I three-point hitch, double cylinder high pressure lifter, maximum lifting force up to 8.27 KN; optional PTO rotation speed 540/720/1000, swing drawbar can be equipped with a variety of implements to meet the needs of different operations.
| Model | Parameters | |
| E504 | Item | Specification |
| Driven Type | 4*4 | |
| Engine Type | 4 cylinder, water-cooled, in-line and four-stroke | |
| Rated Engine Power | 36.8KW/50HP | |
| Clutch | 9 inch double acting clutch | |
| Transmission Type | Synchronizer | |
| Gear | 8F+8R shuttle shift | |
| Hydraulic Output Flow | 36L/min | |
| Overall Dimensions | 3560mm*1680mm*2230mm(ROPS) | |
| Minimum Operating Weight | 1780kg(ROPS) | |
| Tires | 7.5-16/12.4-24(Standard) | |
