LOVOL R SERIES 1804 TRACTOR
Inquire Now
LOVOL R1804 tractor, designed and manufactured by European technology, is a product for dry land and multifunctional applications;
LOVOL Power engine, satisfies the Euro II emission standard, torque reserve coefficient ≥30%, the traction force up to 35KN. Synchronizer 16F+8R gear, easy to shift; body appearance upgrade, high handling comfort;
LUK clutch, the American Actuant instrument, standard CARRARO front axle, strengthened chassis and rear axle; core parts and components are purchased from all over the world with high reliability. Multiple tire options; optional internal and external air filter; upper exhaust; cut-off air brake available; rotational moulding 350L oil tank.
?Four-way hydraulic output; Category III three-point hitch(Optional Category II); standard high pressure lifter, maximum lifting force up to 40KN; optional electronic wet-type PTO, maximum lifting force up to 45KN; optional 6/8/21 splines switch PTO output spline shaft, PTO rotation speed 540/720/850/1000 available; swing drawbar can be equipped with a variety of agricultural implements, to meet the needs of different operations;
-
LOVOL R1804 tractor, designed and manufactured by European technology, is a product for dry land and multifunctional applications;
-
LOVOL Power engine, satisfies the Euro II emission standard, torque reserve coefficient ≥30%, the traction force up to 35KN. Synchronizer 16F+8R gear, easy to shift; body appearance upgrade, high handling comfort;
-
LUK clutch, the American Actuant instrument, standard CARRARO front axle, strengthened chassis and rear axle; core parts and components are purchased from all over the world with high reliability. Multiple tire options; optional internal and external air filter; upper exhaust; cut-off air brake available; rotational moulding 350L oil tank.
-
Four-way hydraulic output; Category III three-point hitch(Optional Category II); standard high pressure lifter, maximum lifting force up to 40KN; optional electronic wet-type PTO, maximum lifting force up to 45KN; optional 6/8/21 splines switch PTO output spline shaft, PTO rotation speed 540/720/850/1000 available; swing drawbar can be equipped with a variety of agricultural implements, to meet the needs of different operations;
| Model | Parameters | |
| R1804 | Item | Specification |
| Driven Type | 4*4 | |
| Engine Type | 6 cylinder, water-cooled, in-line and four-stroke | |
| Rated Engine Power | 132.3KW/180HP | |
| Clutch | 14 inch double acting clutch | |
| Transmission Type | Synchronizer | |
| Gear | 16F+16R | |
| Hydraulic Output Flow | 80L/min | |
| Overall Dimensions | 5300mm*2300mm(Single tire outer edge)/3400(Double tires outer edge)*3150mm(CAB) | |
| Minimum Operating Weight | 6250kg(CAB, single tire)/7050(CAB, double tire) | |
| Tires | 16.9-28/20.8-38 single rear tire(Standard) 16.9-30/20.8-42 Double rear tires(Optional) |
|
