LP1-D DC Contactor

Inquire Now View full specifications

Complete the form below to receive a response within 24 hours.

LP1-D DC Contactor

TYPE	reted woring currentA IeA (AC-3)	Rated heat current Ith(A)	rated working voltage UeA	rated insulated voltage UiA
LP1-D09	9	20	380v 660v	660v
LP1-D12	12	20
LP1-D18	18	32
LP1-D25	25	40
LP1-D32	32	50
LP1-D40	40	60
LP1-D50	50	80
LP1-D65	65	80
LP1-D80	80	125
LP1-D95	95	125

TYPE	controlled power KW					Electrical life (AC-3)104	contacts number
TYPE	220V	380V	415V	440V	660V
LP1-D09	2.2	4	4	4	5.5	660V
LP1-D12	3	5.5	5.5	5.5	5.5
LP1-D18	4	7.5	9	9	9
LP1-D25	5.5	11	11	11	11		3P+NO
LP1-D32	7.5	15	15	15	18.5		3P+NC
LP1-D40	11	18.5	22	22	30
LP1-D50	15	22	25	30	33		3P+NO+NC
LP1-D65	18.5	30	37	37	37
LP1-D80	22	37	45	45	45
LP1-D95	25	45	45	45	45
