LPG/NG Generator 2.0/2.5/5.0kw
Inquire NowDescription
The LPG/NG Generator offers reliable and efficient energy solutions with three powerful models designed to cater to various power needs: 2.0KW, 2.5KW, and 5.0KW. These generators are expertly engineered for versatility, operating seamlessly on both liquefied petroleum gas (LPG) and natural gas (NG). They feature a brush type, single-phase design to ensure stable power output. Ideal for home, worksite, or outdoor use, this generator guarantees dependable performance for all your energy requirements.
Specifications
| Feature | 2.0KW Model | 2.5KW Model | 5.0KW Model |
|---|---|---|---|
| Generator Model | PG2500L/N（E） | PG3000L/N（E） | PG6500L/N（E） |
| Type | Brush type, Single-phase, LPG/NG | ||
| Rated Voltage | 110V, 120V, 220V, 230V, 240V, 110V/220V, 120V/240V | ||
| Rated Frequency | 50Hz/60Hz | ||
| Rated Output | 2.0KW/2.2KW | 2.5KW/2.7KW | 4.5KW/5.0KW |
| Max. Output | 2.2KW/2.5KW | 2.7KW/3.0KW | 5.0KW/5.4KW |
| Power Factor | COSφ=0.75 | COSφ=0.75 | COSφ=0.8 |
| Engine Model | PW200 | PW210 | PW390 |
| Displacement | 196cc | 208cc | 389cc |
| Net Power | 3.33KW/3600rpm | 3.6KW/3600rpm | 7.50KW/3600rpm |
| Bore×Stroke | 68mm×54mm | 70mm×54mm | 88mm×64mm |
| Fuel Type | LPG or NG | ||
| Fuel Tank Capacity | LPG:0.34kg/kw.h NG:0.36m³/kw.h | LPG:0.34kg/kw.h NG:0.36m³/kw.h | LPG:0.32kg/kw.h NG:0.35m³/kw.h |
| Oil Type | SF or Higher Grade | ||
| Oil Capacity | 0.6L | 0.6L | 0.6L |
| Noise | 67dB | 67dB | 70dB |
| Lubrication | Splash | ||
| Starting System | Recoil start/Electric-start | ||
| Choke Type | Manual Lever | ||
| Dry Weight | 42.5Kg/49.5Kg | 51.5Kg/58.5Kg | 85.0Kg/95.0Kg |
| Dimensions (LxWxH) | 605 mm×455 mm×475mm/675 mm×465 mm×475mm | 605 mm×455 mm×470mm/605 mm×465 mm×470mm | 705 mm×595 mm×575mm/712 mm×595 mm×575mm |
| 20FT/40FT/40HQ | 227/456/456 | 227/456/456 | 128/256/256 |
Additional Information
These generators come equipped with both recoil and electric start options, providing users the flexibility to start the unit with ease. The manual lever choke type ensures simple operation, while the splash lubrication system enhances engine longevity. Ideal for both residential and commercial applications, these generators deliver efficiency and reliability across various settings.
