OEM ODM LT955
Description
The LT955 is a robust 5-ton front-end wheel loader, engineered for efficiency and durability in various applications. Featuring cutting-edge technologies, this loader enhances fuel efficiency and safety through innovations like Auto Cooling Technology in the brake system and a dust-proof layer that extends the axle’s lifespan. Designed with a powerful hydraulic system, it optimally utilizes engine power, reducing energy consumption while ensuring exceptional performance. The spacious cabin, coupled with user-friendly controls, allows for comfortable and intuitive operation, making it ideal for both seasoned operators and novices alike.
Specifications
| Attribute | Value |
|---|---|
| Operating weight | 16000kg |
| Rated load | 5000kg |
| Bucket capacity | 3m³ |
| Engine model | WEICHAI WD10G220E23 |
| Rated power | 162KW |
| Rated rotate speed | 2000r/min |
| Max torque | 745.3N.m |
| Breakout force | 145KN |
| Forward 1 | 0-11.5 km/h |
| Forward 2 | 0-38 km/h |
| Reverse 1 | 0-16 km/h |
| Grade ability | 28 |
| Overall length | 7460mm |
| Overall Width | 2870mm |
| Overall height | 3220mm |
| Bucket width | 3000mm |
| Wheel base | 2820mm |
| Track base | 2260mm |
| Min. ground clearance | 450mm |
| Max. dumping height | 3100mm |
| Max. dumping reach | 1310mm |
| Transmission | Planet-type |
| Raise time | ≤ 6.8s |
| Total | ≤ 12.5 |
| Tire type | 23.5-25 |
Additional Information
- Exclusive patent: Incorporates proprietary technologies for increased fuel efficiency and safety.
- Structural details: Enhanced carrying capacity with bigger hinge components for improved power.
- Humanized design: Spacious cabin with a broad view and easy operation controls.
- Hydraulic system: Dual pump confluence system designed for efficient engine power usage.
- Optional attachments: Compatible with a variety of attachments including floating forks and snow blades.
