LXZ Series WL/R (LoRaWAN) Smart Water Meter
Inquire Nowhtml
Description
The LXZ Series WL/R (LoRaWAN) Smart Water Meter is a cutting-edge solution designed for efficient water consumption tracking. This wireless smart meter integrates a remote-based water meter with advanced wireless communication modules. It enables seamless point-to-point data collection through a gateway, ensuring low power consumption, extended battery life, and two-way data transmission. With its automated daily data uploads to the gateway and onward to the network platform, this meter guarantees precise real-time data collection and reliable performance.
Featuring a simple structure, the LXZ Series is easy to install and maintain, requiring no cabling for connections. Its durable design and IP68 protection grade make it suitable for various environmental conditions, ensuring long-lasting operation.
Specifications
| Attribute | Details |
|---|---|
| Operating Environment | Water Temperature: 0.1℃～30℃ Protection Grade: IP68 |
| Operating Water Pressure | 0.03MPa~1.0MPa |
| Pressure Loss | ≤0.1MPa |
| Electromechanical Conversion Error | ≤±0.5m³ |
| Allowable Maximum Error | From minimum flow to low zone (not including demarcation flow): ±5%; From demarcation flow to high zone (including overload flow): ±2% |
| Communication Distance | City transmission distance: About 2km Number of floors crossed: About 15 floors |
| Power Supply | External 220V power supply required for the gateway |
| Data Storage | All prepaid costs stored in the meter reading system |
Additional Information
Power consumption for the LXZ Series WL/R includes:
- Static current consumption (wireless module): ≤10µA
- Control current consumption (measurement): <1mA
- Control current consumption (ON/OFF control): <200mA
- Wireless current receiving power consumption: ≤20mA
- Wireless current emission power consumption: About 150mA
The meter operates on a 3.6V lithium battery, ensuring a lifespan of over 10 years, making it a reliable choice for continuous water monitoring.
