Manual forklift

The manual hydraulic stacker is a non-pollution, non-powered loading and unloading product. The product has the characteristics of compact structure, flexible transportation, simple operation and small turning radius. It is suitable for cargo handling and stacking in factories, workshops, warehouses, stations, docks, etc. It is more suitable for those sites with fire and explosion protection requirements (such as printing workshops, oil depots, docks, warehouses, etc.). If combined with pallet packing, containers, etc. and unitized transportation can be realized, the collision, scratching and stacking area of parts are effectively reduced, the workload of transportation is reduced, and the transportation efficiency is improved. Single door frame structure design, small turning radius, suitable for machinery manufacturing, paper making, printing, handling, logistics and other industries.

Model MST-A1.0 MST-A2.0 MST-A3.0
Rated load(kg) 1000 2000 3000
Lifting height(mm) 1600 1600 1600
Door frame material 10#Channel steel 12#I-beam 16#I-beam
Height of fork lowered(mm) 85 85 100
Fork length(mm) 900 900 1000
Fork regnlate width(mm) 230-580 270-680 320-770
Lifting speed(mm/stroke) 20 14 10
Lowering speed(mm/stroke) can control can control can control
Front leg width(mm) 750 750 750
Handle operating force(kg) 24 32 40
Min.fuel quantity(L) 1.6 2.0 3.0
Front wheel dimension(mm) Φ85*50 Φ 85*50 Φ100*50
Rear wheel dimension(mm) Φ 180*50 Φ180*50 Φ180*50
Dimension(mm) 2040*750*1420 2050*750*480 2050*800*1650
Net.Weight(kg) 115 180 280
