MCB Type Isolator Switch Main Switch DIN Type for Distribution Box
Inquire NowDescription
The MCB Type Isolator Switch is an essential component for any distribution box, designed to provide reliable electrical isolation. This DIN type switch ensures safety and efficiency by enabling the user to disconnect the power supply quickly. With multiple rated currents available (32A, 40A, 50A, 63A, 80A, 100A, and 125A), it caters to various electrical needs. Its robust construction and high-rated impulse withstand voltage of 4,000V make it suitable for both residential and industrial applications.
Specifications
| Attribute | Details |
|---|---|
| Rated Voltage Ue | 240/415V |
| Rated Current le | 32, 40, 50, 63, 80, 100, 125A |
| Poles | 1P, 2P, 3P, 4P |
| Rated Frequency | 50/60Hz |
| Rated Impulse Withstand Voltage | 4,000V |
| Rated Short-time Withstand Current | 12le, 1s |
| Rated Making and Breaking Capacity | 3le, 1.05Ue, cos Φ =0.65 |
| Dielectric Test Voltage | 2.5kV |
| Insulation Voltage Ui | 500V |
| Pollution Degree | 2 |
| Utilization Category | AC-22A |
| Electrical Life | 1,500 |
| Mechanical Life | 8,500 |
| Protection Degree | IP20 |
| Storage Temperature | -25°C to +70°C |
Additional Information
Installation:
Terminal connection type: Cable/Pin-type busbar
Terminal size (top/bottom for cable): 50mm²
Terminal size (top/bottom for busbar): 50mm²
Tightening torque: 2.5 N*m
Connection: From top and bottom.
