Mechanical type
Inquire NowDescription
The Mechanical Type series offers a robust solution for various industrial applications, providing efficient performance and reliable operation. Each model is designed to meet specific requirements in terms of volume, power input, and operational efficiency. With a focus on user-friendly features, these units are equipped to handle set-point temperatures of up to 65°C and a consistent working pressure of 0.7 MPa. The series includes a range of models from GD100 to GD500, catering to diverse operational needs.
Specifications
| Model | Volume (L) | Voltage/Frequency | Input Power (kW) | Set Point Temperature (°C) | Working Pressure (MPa) | Overall Dimension (φmm × H mm) | Installation Size of Water Pipe |
|---|---|---|---|---|---|---|---|
| GD100××JA | 100 | AC 220V/50Hz | 1.5, 2, 2.5, 3, 4, 5 | 65 | 0.7 | φ450 × 1105 | 3/4″ |
| GD150××JA | 150 | AC 220V/50Hz | 1.5, 2, 2.5, 3, 4, 5 | 65 | 0.7 | φ450 × 1570 | 3/4″ |
| GD200××JA | 200 | AC 220V/50Hz | 2, 2.5, 3, 4, 5, 6 | 65 | 0.7 | φ520 × 1530 | 3/4″ |
| GD250××JA | 250 | AC 220V/50Hz | 2.5, 3, 4, 5, 6, 8 | 65 | 0.7 | φ620 × 1280 | 3/4″ |
| GD300××JA | 300 | AC 220V/50Hz | 2.5, 3, 4, 5, 6, 8 | 65 | 0.7 | φ620 × 1530 | 3/4″ |
| GD500××JA | 500 | AC 220V/50Hz | 5, 6, 8 | 65 | 0.7 | φ710 × 1580 | 3/4″ |
| GD200××JB | 200 | AC 380V/50Hz | 2.5, 4, 6, 8, 9 | 65 | 0.7 | φ520 × 1530 | 3/4″ |
| GD300××JB | 300 | AC 380V/50Hz | 2.5, 4, 6, 8, 9, 12 | 65 | 0.7 | φ620 × 1530 | 3/4″ |
| GD500××JB | 500 | AC 380V/50Hz | 6, 8, 9, 12 | 65 | 0.7 | φ710 × 1710 | 3/4″ |
