Description

The Mini SCADA system is a cutting-edge solution designed for modular and distributed data management in substation automation. With a focus on flexibility, this software enables seamless configuration and troubleshooting, allowing each module—such as Front End Server, SCADA Server, Database Server, and various workstations—to operate on multiple machines. Its bay-oriented data management system simplifies the implementation of interlocking for remote control functions, ensuring efficient data handling.

Utilizing a robust Ethernet-based platform, the Mini SCADA system provides real-time data access across all nodes, enhancing safety and reliability. The open architecture design is user-friendly, featuring a graphical human-machine interface compatible with standard SQL databases. It supports TCP/IP protocol for dependable communication and integrates easily with other systems, making it an ideal choice for modern automation needs.

Key Functions:

• Data Acquisition
• Data Processing and Computing
• Human Machine Interface
• Remote Control Operation
• Event Recording
• Alarm Function
• Report Management
• User Authority Function
• Database Management and Maintenance
• System Self Diagnose Function
• Protection Relay Management
• Fault Recording Data Processing and Analyzing
• Interlocking and Operating Ticket
• VQC
