miniature circuit breaker MCB DZ47-63
Inquire NowDescription
The Miniature Circuit Breaker (MCB) DZ47-63 is an essential device designed to protect electrical circuits from overloads and short circuits. Engineered for reliability and efficiency, this circuit breaker combines advanced technology with user-friendly features, making it an ideal choice for both residential and commercial applications. With its robust design and various options for rated current, the DZ47-63 ensures optimal safety and performance, providing peace of mind in your electrical installations.
Specifications
| Attribute | Details |
|---|---|
| Model | Mini Circuit Breaker |
| Type | DZ47-63 YFB1-63 |
| Origin | Zhejiang, China |
| Standard | IEC 60898 / GB10963.1 |
| Rated Current | 6; 10; 16; 20; 25; 32; 40; 50; 63A |
| Poles | 1P; 2P; 3P; 4P |
| Rated Voltage Ue | 230/400V |
| Isolation Voltage Ui | 600V |
| Rated Frequency | 50/60Hz |
| Rated Breaking Capacity | 6000/4500A |
| Power Factor | 0.65~0.70, 0.75~0.80 |
| Max Current that does not trigger | 1.13In |
| Heat Resistance Category | 2 |
| Protection Class | IP 20 |
| Pollution Degree | 2 |
| Electrical Life | 4000 cycles |
| Mechanical Life | 10000 cycles |
| Ambient Temperature | -5 ~ +35°C |
| Terminal Connection Type | Cable/Pin-type busbar |
| Mounting | 35mm DIN rail |
| Wiring | With clamp, cable diameter max 25mm |
Additional Information
- Selling Units: Single item
- Single package size: 120X60X60 cm
- Single gross weight: 10.000 kg
- Package Type: ctn
