Description
The PB8H Miniature Circuit Breaker is engineered for superior overload and short-circuit protection, making it an essential component for reliable electrical systems. This versatile breaker supports Curve B, C, and D, ensuring compatibility with various applications. The device features a clear contact position indication window, displaying green for ON and red for OFF, allowing for quick visual checks. With a rated short-circuit breaking capacity of 10kA, it provides robust protection against electrical faults.
Designed for flexibility, the PB8H comes in 1-4 pole versions and supports rated currents of up to 63A. It operates efficiently at a rated working voltage of 50/60Hz. This circuit breaker adheres to the IEC/EN 60898-1 standard and is certified with CE/KEMA, ensuring compliance with high safety and quality standards.
Specifications
| Attribute | Details |
|---|---|
| Type | Miniature Circuit Breaker |
| Protection Type | Overload and Short-circuit |
| Curve | B, C, D |
| Contact Indication | Green: ON, Red: OFF |
| Rated Short-circuit Breaking Capacity | 10kA |
| Conditional Rated Short Circuit Strength | 6kA |
| Versions | 1-4 Pole |
| Rated Current | Up to 63A |
| Rated Working Voltage | 50/60Hz |
| Standards | IEC/EN 60898-1 |
| Certification | CE/KEMA |
