MJ6130TZ
Inquire NowDescription
The MJ6130TZ is a high-performance sliding table saw designed for precision cutting in woodworking applications. Engineered for durability and efficiency, this powerful machine boasts a gross cut capacity of 3100mm and features an impressive 300mm saw blade, adjustable for a variety of cutting tasks. With a robust main motor delivering 4kw, the MJ6130TZ effortlessly handles even the toughest materials, making it an indispensable tool for both professionals and serious hobbyists.
Its tilting saw blade allows for angled cuts up to 45°, providing versatility in your projects. The machine’s design includes a scoring saw blade with a speed of 8000r/min, ensuring clean edges and minimizing tear-out. Coupled with a net weight of 1000kg, the MJ6130TZ remains stable during operation, while its compact overall dimensions make it suitable for various workshop environments.
Specifications
| Attribute | Details |
|---|---|
| Gross Cut Capacity | 3100mm |
| Sliding Table Dimensions | 3000/3200×360mm |
| Width of Cut Between Saw Blade and Rip Fence | 1250mm |
| Main Saw Blade Diameter | 300mm (250-300) |
| Height of Cut | 300mm |
| Height of Cut at 45° | 55mm |
| Main Saw Blade Speed | 4000/6000rpm |
| Spindle Diameter | 30mm |
| Tiling Saw Blade Angle | 0-45° |
| Main Motor Power | 4kw |
| Scoring Saw Blade Diameter | 120mm |
| Speed of Scoring Saw Blade | 8000r/min |
| Spindle of Scoring Saw | 20mm |
| Scoring Motor Power | 0.75kw |
| Net Weight | 1000kg |
| Gross Weight (Wooden Packing Case) | 1050kg |
| Overall Dimensions | 3050/3150×3250×900mm |
Additional Information
- Designed for precision and efficiency in woodworking.
- Ideal for both professional and hobbyist use.
- Stable operation due to substantial weight.
