MLN COLD SHRINKABLE TERMINATION ACCESSORIES(Indoor)
Inquire NowDescription
The MLN Cold Shrinkable Termination Accessories are designed for seamless indoor application, ensuring superior connectivity and insulation for cables. These innovative accessories utilize pre-expanded components on an easy-to-remove spiral holdout, allowing for quick and efficient installation without the need for tools, torches, or heat sources. The cold shrinkable tubing fits tightly around the cables, providing outstanding resilience and durability. Featuring integrated geometric stress control and void-filling mastic, these accessories minimize termination positioning errors, ensuring reliable performance.
Made from high-quality silicone-rubber, the materials offer exceptional UV resistance, anti-tracking properties, and hydrophobic characteristics, promoting a long service life. Suitable for insulated PVC, PE, and XLPE polymeric cables rated up to 8.7/15(17.5)kV, the MLN Cold Shrinkable Termination Accessories are fully tested in accordance with IEC 60502-4, making them ideal for both copper and aluminum alloy conductors.
Specifications
| Attribute | Details |
|---|---|
| Voltage Rating | Up to 8.7/15(17.5)kV |
| Applications | Indoor use for PVC, PE, and XLPE insulated cables |
| Material | Silicone-Rubber |
| Installation Method | Cold Shrinkable, no tools required |
| Testing Standard | IEC 60502-4 |
Additional Information
- Outstanding resilience and tight fit for cables
- Excellent insulation performance
- Integrated stress control for reduced installation errors
- Long service life with high UV resistance and hydrophobic properties
