MODULAR DISTRIBUTION BLOCKS
Inquire NowDescription
Introducing the Modular Distribution Blocks, a versatile solution for efficient electrical distribution. These blocks are designed for seamless connections with or without ferrules, ensuring flexibility for various wiring configurations. Each unit is supplied with an insulated back plate and a transparent protective front cover that is self-extinguishing for enhanced safety. The installation methods are straightforward; you can fix them onto a din-rail or mount them directly onto a plate using screws. Additionally, these blocks allow for under-plate installation with optional blanking plates.
Each bar is equipped with insulation protection, and can be easily labeled using cab 3TM for clear identification. Designed in compliance with the EN60947-1 standard and capable of withstanding an ICC of 20kA peak, these distribution blocks guarantee reliability and safety in your electrical applications.
Specifications
| Item No. | Bus Bar Spec. | No. Of Bus Bar |
Conductors with starfix ferrules X-section (mm²) |
Cond. W/ out ferr. X-section (mm²) |
Dimensions (L×W×H) (mm) |
|---|---|---|---|---|---|
| VC-207 | 5×φ5.3mm 2×φ7.5mm |
2 | 1.5 to 6 6 to 16 |
2.5 to 6 10 to 25 |
65×42×50 |
| VC-211 | 7×φ5.3mm 2×φ7.5mm 2×φ8.5mm |
2 | 1.5 to 6 6 to 16 10 to 16 |
2.5 to 6 10 to 25 10 to 35 |
100×42×50 |
| VC-215 | 11×φ5.3mm 2×φ7.5mm 2×φ8.5mm |
2 | 1.5 to 6 6 to 16 10 to 16 |
2.5 to 6 10 to 25 10 to 35 |
133×42×50 |
| VC-407 | 5×φ5.3mm 2×φ7.5mm |
4 | 1.5 to 6 6 to 16 |
2.5 to 6 10 to 25 |
65×88×50 |
| VC-411 | 7×φ5.3mm 2×φ7.5mm 2×φ8.5mm |
4 | 1.5 to 6 6 to 16 10 to 16 |
2.5 to 6 10 to 25 10 to 35 |
100×88×50 |
| VC-415 | 11×φ5.3mm 2×φ7.5mm 2×φ8.5mm |
4 | 1.5 to 6 6 to 16 10 to 16 |
2.5 to 6 10 to 25 10 to 35 |
133×88×50 |
Additional Information
- Connection can be made with or without ferrules.
- Comes with an insulated back plate and a transparent protective front cover.
- Mounting methods include fixing on a din-rail or directly onto a plate.
- Supports labeling for each bar.
- Complies with standard EN60947-1.
