MSC
Inquire NowDescription
The MSC centrifugal multistage low head water pump is designed for high flow rate irrigation systems, making it an ideal choice for gardening, agricultural, and industrial applications. This versatile pump efficiently handles clean water and non-aggressive liquids with minimal solid impurities, ensuring optimal performance in various settings. Engineered for continuous duty, the MSC pump operates under demanding conditions, providing reliability and durability.
Specifications
| Attribute | Details |
|---|---|
| Max. Working Pressure | 5.5 bar |
| Liquid Temperature | Up to 60°C |
| Ambient Temperature | Up to 40°C |
| Total Suction Lift | Up to 9 m |
| Motor Type | Two-pole induction motor (n=2850 r.p.m) |
| Insulation Class | B |
| Protection Rating | IP44 |
| Pump Body Material | Stainless Steel |
| Motor Support Material | Cast Iron |
| Motor Housing Material | Aluminum |
| Impeller Material | PPO |
| Shaft Material | Superior Steel |
| Mechanical Seal | Carbon/Ceramic |
| Voltage Options | Single phase 220V-240V/50Hz, Single phase 110V-127V/60Hz (upon request), Single/Three phase 220V/60Hz (upon request) |
Additional Information
- Designed for flow irrigation systems.
- Suitable for a variety of agricultural and industrial applications.
