Multistage Vertical Centrifugal Jockey Pump PV

Inquire Now

Description

The Multistage Vertical Centrifugal Jockey Pump PV is the epitome of modern engineering, specifically designed for optimal performance and energy efficiency. This innovative pump features a noiseless operation, ensuring that it functions quietly without compromising on power. With its durable construction and user-friendly design, the PV series guarantees reliability in various applications.

Equipped with a high-efficiency YE3 motor featuring an IP55 class F protection rating, this pump excels in demanding environments. The pump’s robust impeller is crafted from techno-polymer, while its suction and discharge ports are made of cast iron G20 thread, providing superior strength and resistance to wear. Furthermore, the integration of quality NSK bearings and a wear-resistant mechanical seal contributes to its long-lasting performance.

Its versatility allows it to handle clean water and non-aggressive liquids, making it suitable for diverse applications spanning domestic, civil, and industrial sectors. Ideal for water distribution in combination with pressure sets and for pressure boosting, this pump is engineered to adapt to a wide range of operational demands.

Specifications

Attribute Details
Motor Type YE3 High Efficient Motor
Protection Class IP55, Class F
Impeller Material Techno-Polymer
Suction & Discharge Port Cast Iron G20 Thread
Shaft Material Stainless Steel AISI 304 or Galvanized Iron
Bearings NSK Quality Bearings
Liquid Temperature Range -10℃ to +120℃
Ambient Temperature Up to +50℃
Max Working Pressure 25 Bar
Service Type Continuous Service S1

Additional Information

  • Ideal for use in domestic, civil, and industrial sectors.
  • Suitable for the distribution of water in combination with pressure sets.
  • Engineered to adapt to unusual applications, ensuring high efficiency and durability.
