Description

The NF184 series brushless alternator is a powerhouse designed for reliability and efficiency, available in power ratings from 22.5kVA to 47.3kVA. Its compact size and exquisite appearance make it suitable for various applications while ensuring high performance. This alternator features an optional auxiliary winding or phase combination excitation system, allowing it to withstand short-circuit currents. With a permanent magnet generator system available, it guarantees constant excitation under all conditions.

Equipped with an advanced automatic voltage regulation system, the NF184 ensures stable operation even in the most demanding environments. The innovative design includes a reorganization of the first twelve terminal blocks to meet diverse voltage requirements and a standard 2/3 pitch winding that minimizes neutral currents, facilitating parallel operation with other generators.

Its unique convex pole rotating magnetic field design enhances heat dissipation and increases the mechanical strength of the winding coil. Installation and maintenance are simplified with accessible terminals, rotating diodes, and bolt shafts. The alternator meets all leading diesel land mounting interface standards with its single-pivot and full-pivot structure. Additionally, full continuous damping winding and 2/3 pitch winding significantly reduce output voltage waveform distortion, telephone harmonic factors, and interference.

Specifications

Additional Information

For optimal performance, ensure regular maintenance and check the voltage settings according to your specific requirements. The alternator’s design allows for easy installation and operation, making it a reliable choice for various applications.
