permanent lifting magnet
Inquire NowDescription
The Permanent Lifting Magnet is a powerful, compact, and reliable device designed for safe and efficient handling of a wide array of metal workpieces. From sheets to plates, and flat to round shapes, these magnets offer ergonomic operation and require no electricity, making them an ideal solution for various industries such as molding and steel manufacturing. Featuring a flexible rotation handle for easy activation and deactivation, each lifter is crafted with safety in mind, incorporating robust materials and a safety latch for secure lifting.
Specifications
| Model | Rated Capacity (Steel Plate) | Min. Steel Plate Thickness | Max. Steel Plate Length | Net Weight |
|---|---|---|---|---|
| PML-100 | 100 kg | 15 mm | 1000 mm | 3 kg |
| PML-400 | 400 kg | 25 mm | 1500 mm | 9 kg |
| PML-600 | 600 kg | 30 mm | 2000 mm | 20 kg |
| PML-1000 | 1000 kg | 40 mm | 3000 mm | 36 kg |
| PML-2000 | 2000 kg | 55 mm | 3000 mm | 68 kg |
| PML-3000 | 3000 kg | 60 mm | 3000 mm | 80 kg |
| PML-5000 | 5000 kg | 70 mm | 3000 mm | 192 kg |
Additional Information
Key Features:
- Constructed with Neodymium N42 or N45 magnets, ensuring a high safety factor.
- Flexible rotation handle for straightforward magnetism activation and deactivation.
- Durable lifting shackle made from alloy steel with chrome coating.
- V-shaped bottom design increases contact area and magnetic strength.
