PM16/AUTOPM16 Peripheral Pump
Inquire NowDescription
The PM16/AUTOPM16 Peripheral Pump is an efficient solution designed for small-scale booster systems, ideal for domestic water circulation and small-scale irrigation applications. With its robust construction and advanced engineering, this pump ensures reliable performance in various conditions. It is engineered to handle a suction lift of 6-8 meters when equipped with a foot valve, making it suitable for a range of water lifting tasks. Its maximum operating pressure of 8 bar and capability to operate at ambient temperatures of up to +40℃ further enhance its versatility.
Specifications
| Attribute | Details |
|---|---|
| Suction Lift | 6-8 m with foot valve |
| Maximum Operating Pressure | 8 bar |
| Maximum Ambient Temperature | +40℃ |
| Liquid Temperature | +90℃ |
| Maximum Altitude | 1000 m |
| Pump Body | Cast Iron |
| Impeller | Brass |
| Motor Shaft | AISI 1045 |
| Mechanical Seal | NBR/Graphite/Ceramic |
Additional Information
The PM16/AUTOPM16 Peripheral Pump adheres to various product standards, including IEC60034-1, IEC 335-1, IEC 34-1, and ISO 2548, ensuring its reliability and quality in performance.
